W 英國(guó)惠氏螺紋55°螺紋刀片
內(nèi)切圓 mm | 螺 距 TPI | 型 號(hào) | H | L | B | α | ||
右螺紋 | 左螺紋 | |||||||
外 螺 紋
| 9.525
| 28 26 24 22 20 19 18 16 14 12 11 10 9 8 | 16ER28W 16ER26W 16ER24W 16ER23W 16ER20W 16ER19W 16ER18W 16ER16W 16ER14W 16ER12W 16ER11W 16ER10W 16ER9W 16ER8W | 16EL28W 16EL26W 16EL24W 16EL23W 16EL20W 16EL19W 16EL18W 16EL16W 16EL14W 16EL12W 16EL11W 16EL10W 16EL9W 16EL8W | 15.7 15.7 15.7 15.7 15.7 15.7 15.7 15.3 15.3 15.3 15.3 15.3 15.3 15.3 | 0.8 0.8 0.8 0.8 0.8 1.0 1.0 1.5 1.5 1.5 1.5 1.5 1.5 1.5 | 3.65 | 10° |
12.7 | 6 | 22ER6W | 22EL6W | 20.2 | 2.5 | 4.76 | ||
內(nèi) 螺 紋
|
9.525 | 28 26 24 22 20 19 18 16 14 12 11 10 9 8 | 16NR28W 16NR26W 16NR24W 16NR23W 16NR20W 16NR19W 16NR18W 16NR16W 16NR14W 16NR12W 16NR11W 16NR10W 16NR9W 16NR8W | 16NL28W 16NL26W 16NL24W 16NL23W 16NL20W 16NL19W 16NL18W 16NL16W 16NL14W 16NL12W 16NL11W 16NL10W 16NL9W 16NL8W | 15.7 15.7 15.7 15.7 15.7 15.7 15.7 15.3 15.3 15.3 15.3 15.3 15.3 15.3 | 0.8 0.8 0.8 0.8 0.8 1.0 1.0 1.5 1.5 1.5 1.5 1.5 1.5 1.5 | 3.65 | 15° |
12.7 | 6 | 22NR6W | 22NL6W | 20.2 | 2.5 | 4.76 | ||
